Efficient and Precise I-Shaped Straw Packing Machine

Automate your straw packaging process with our cutting-edge machine, designed for precision and high-volume operations. Reliable, fast, and easy to use.

High-Speed Packing for Straight Straws

Our I-Shaped Straw Packing Machine is built for efficient, high-speed packing of straight (I-shaped) straws into individual wrappers. The machine ensures precise, hygienic packaging for straws, making it ideal for manufacturers serving fast food chains, beverage companies, and retail outlets. This fully automated solution helps increase productivity, reduce labor costs, and maintain consistency across production batches.

drinking straw packing and cutting machine

Key Features

1. Packing single straw in a row, Complete stuffing and packing at a time;

2. Automatic counting and batch alarm;

3. Adjustable packing speed;

4. Automatic stop when lack of straw

5. Can cut the straw at preset quantity

작동 중인 밀짚 포장기 시청하기

기술 사양

구동모터	0.75kw controlled by frequency converter
생산능력	Straight straws	600~700 pcs/min
생산능력	Flexible straws	350~450 pcs/min
Specifications of wrapping material	Four sides sealing (Serrated)Can be cut into single pieces or 4、5、10、 20pcs/piece
	재료	BOPP 필름
	필름의 두께	20m-30m
	Roll diameter	Max:340mm
	Inside diameter of the roll	75mm
	Width of the film	최대 : 280mm
포장 형태	15mm(Pitch）×96~250mm(Width), Other specifications are Customized
Straw specifications	Straw diameter	Ø 2.5~ Ø7mm
	Straw wall thickness	0.15~0.25mm
	길이	90~255mm(Standard)
다른 사양은 사용자 정의됩니다
기계 크기	2000× 900 × 1600mm
기계 중량	600kg
