Efficient and Precise I-Shaped Straw Packing Machine
Automate your straw packaging process with our cutting-edge machine, designed for precision and high-volume operations. Reliable, fast, and easy to use.
High-Speed Packing for Straight Straws
Our I-Shaped Straw Packing Machine is built for efficient, high-speed packing of straight (I-shaped) straws into individual wrappers. The machine ensures precise, hygienic packaging for straws, making it ideal for manufacturers serving fast food chains, beverage companies, and retail outlets. This fully automated solution helps increase productivity, reduce labor costs, and maintain consistency across production batches.
Key Features
1. Packing single straw in a row, Complete stuffing and packing at a time;
2. Automatic counting and batch alarm;
3. Adjustable packing speed;
4. Automatic stop when lack of straw
5. Can cut the straw at preset quantity
Watch the Straw Packing Machine in Action
Tegniese spesifikasie
| Driving motor | 0.75kw controlled by frequency converter | |
| Production capacity | Straight straws | 600~700 pcs/min |
| Flexible straws | 350~450 pcs/min | |
| Specifications of wrapping material | Four sides sealing (Serrated)Can be cut into single pieces or 4、5、10、 20pcs/piece | |
| Materiaal | BOPP Film | |
| Dikte van film | 20m-30m | |
| Roll diameter | Max:340mm | |
| Inside diameter of the roll | 75mm | |
| Width of the film | Maksimum: 280 mm | |
| Verpakkingsvorm | 15mm(Pitch）×96~250mm(Width), Other specifications are Customized | |
| Straw specifications | Strooi deursnee | Ø 2.5~ Ø7mm |
| Straw wall thickness | 0.15~0.25mm | |
| Length | 90~255mm(Standard) | |
| Ander spesifikasies is pasgemaak | ||
| Masjien grootte | 2000× 900 × 1600mm | |
| Masjien gewig | 600kg | |
Packing Displays
Verken meer strooiproduksie-oplossings
Looking for more straw manufacturing equipment? Discover our full range of machines designed to optimize your entire production process.
