Join the Eco-Friendly Movement with Our High-Performance Paper Straw Making Machine
Produce biodegradable paper straws efficiently with precision and speed, ensuring sustainable and high-quality products for a plastic-free future.
Efficient and Sustainable Paper Straw Production
Welcome to the world of paper straw making machines - an innovative and efficient solution for businesses looking to switch to eco-friendly drinking straw. Our machines are designed to streamline the production process, incorporating a range of features to ensure smooth and reliable operation. The whole system includes a paper roll hanging bracket, capable of holding 4 layers of paper and auto-connecting/splicing for uninterrupted production. The glue station is made of stainless steel and features automatic glue feeding, while the winding and control mechanism ensures precision and efficiency in the manufacturing process. Our machines also feature a multi-cutting system, with 8 cutting knives equipped with dust and protective covers for worker safety. A conveyor and collector complete the system, allowing for easy transportation and storage of finished products. Discover the benefits of our state-of-the-art paper straw making machines today and make the switch to environmentally-friendly paper straws
From Left to right: Paper Roll brackets, Glue Station, Winding & control mechanism, Multi Cutting System, Conveyor, Collector
Why Choose Our Paper Straw Making Machine?
1
High-speed production up to 105m/min input and 80m/min output.
4
Auto paper roll connecting function with 4 layers for uninterrupted production.
2
8 cutting-knife system with new structure for easy air cylinder adjustment.
5
Auto lubrication grease feeding system for optimal cutting system performance.
3
5 servo motors for precise control of spiraling roller, cutting system, and more.
6
Famous brand electrical components, including Schneider, for top-notch quality.
Glue Station
- Aluminum and stainless steel frame;
- Stainless steel glue pot;
- Glue heating function(choosing choice);
- Glue recycle system
- Lubrication oil roller for inner paper strip;
- One pair roller ( rubber roller and steel roller) for filming glue on paper.
- 1 motor to drive glue roller;
- Easy to adjust glue quantity by adjusting the distance between two rollers.
Paper roll bracket with connecting function
- Help paper straw-making machine no stop working.
- Use auto-detection: When the paper roll is running out, the mechanism will cut the tail ends of the old paper roll and connect the new paper roll automatically.
- Smaller dimensions, easy delivery, and moving to adjust the paper feeding angle.
- Construction simpleness. If the paper break, no need to stop to route the paper up and down complicated.
- Constant unwinding force for the paper rolls, to let paper feed more smoothly.
- Our own patent for this connecting mechanism, not copy from others, especially European brands, so no patent problem.
- Optional choose: 4 layers connecting mechanism.
Steps of Paper Straw Making
1. Cutting the Raw Material into Strips
The process starts with large rolls of high-quality, food-safe paper. These rolls are cut into narrow strips of uniform width that will be used to make the straws.
2. Feeding Paper Strips into Brackets
The cut strips are placed in brackets in a straw-making machine. Depending on the design of the straw, these strips may consist of multiple layers (typically three or four) to improve durability and functionality.
3. Gluing the Paper Strips
A non-toxic, water-based adhesive is applied to the strips. This glue is important for holding the layers together as they are wound up. The glue must be safe for food contact because it will come in direct contact with beverages.
4. Spiral Winding Process
The glued strips are wound around a mandrel in a spiral fashion. This step shapes the strips into the cylindrical shape associated with straws and gives them structural integrity.
5. Shaping and Final Bonding
As the paper wraps around the mandrel, additional glue bonds all of the layers together securely. This step ensures that straw holds its shape and has enough thickness to be durable.
6. Cutting to Length
After being shaped, long tubes are cut into individual straws at a cutting station so that all straws produced will be uniform in length according to industry standards.
7. Drying Paper Straws
Once cut, straws are placed in drying chambers where they dry out after being cut . This step is important for setting up glue so that straws maintain their shape during use . Depending on manufacturer , this can involve natural air drying or temperature controlled drying units .
Watch Our Paper Straw Making Machine in Action
Paper Straw Making Machine Specification
| Model | YKZGJ-20 | ||
| Technical Parameter | Main Parts | ||
| Electric power | 380V/ 3phase/ 50Hz | PLC | PanKong |
| Electric consumption | 4.5-6.5Kw/h | Control screen | Schneider |
| FLA | 13.5A | Control program | GD-XJ2.0 |
| Speed | 0-80m/min ( output)
0-105m/min (paper feeding) |
Servo motor driver | Schneider |
| Paper layer | 2-4 layers | Servo motor | Schneider |
| Straw Diameter | 4.3--12mm (out diameter)
3.5--11.3 (inner diameter) |
Frequency converter | Schneider |
| Max thickness | 0.6mm-single side | Circuit breaker | Schneider |
| Min thickness | 0.2mm-single side | Relay | Schneider |
| Straw length | 100--1400mm
Distance between 2 blades |
Signal sensor | Omron |
| Cutting method | 8 knife, pneumatic driving | Encoder | Omron |
| Glue method | Single & double face | Pneumatic cylinder | AIRTAC |
| Length control | Encoder | Bearing | HRB |
| Speed control | Servo tracking | Attached equipment/function | |
| Operator | 1 person | Paper connecting function | Have |
| Mandrel fixing | Screw clamp | Dust & protection cover | Have |
| Synchronism control | Servo belt | Winding roller cover | Have |
| Winding belt tension control | Hand wheel | Cutting knife cover | Have |
| Belt angle control | Hand wheel | Pull force tension sensor | Have |
| Lubrication | Lubrication grease | Auto lubrication grease | Have |
| Dimension and Weight | Constant rewinding force | Have | |
| Main part dimension | 3850×1200×1600mm | Mould Anti-vibration roller | Have |
| Land area dimension | 8000×4500×1900mm | Glue recycle pump | Have |
| Winding roller diameter | 215mm | Cutting system limitation rod | Have |
| Winding roller height | 120mm | Multi-control language | Have |
| Weight | 1400 KG | Stainless steel cover | Optional |
| Attached Spare Parts | |||
| Paper Straw Mould | 3 sets | Winding belt | 15 pcs |
| Cutting blades | 14 pcs | Tool box | Have |
| Air cylinder | 1 pcs | Thinner pull rod clamp | 2 pcs |
| Double adhesive tape | Several for paper roll bracket connecting function | Metal adhesive glue | 2 bottle |
Pros & Cons of Paper Straw
Pros
- Paper straws are biodegradable, making them an environmentally-friendly alternative to plastic straws that can take hundreds of years to decompose.
- Paper straws can be recycled, reducing waste and contributing to a more circular economy.
- Paper straws are made from renewable resources, such as paper pulp and plant-based adhesives, making them a more sustainable choice
Cons
- Paper straws are not as durable as plastic straws and can become soggy or disintegrate when exposed to liquids for prolonged periods.
- Paper straws can be more expensive than plastic straws, which may deter some businesses from making the switch.
- Paper straws are not suitable for hot beverages, as they can become soft and lose their shape when exposed to heat.
Using paper straws can be a good choice for people who are concerned about the environment and want to reduce their plastic waste. As a biodegradable and recyclable alternative to plastic straws, paper straws can help to reduce the negative impact of single-use plastics on the environment.
In terms of the future for paper straws, it is likely that the demand for sustainable and eco-friendly alternatives to plastic straws will continue to grow, and paper straws are positioned to be a key player in this market. However, there may be challenges in terms of cost, durability, and availability that will need to be addressed to ensure the widespread adoption of paper straws.
In addition, continued innovation and development in the field of sustainable materials and manufacturing processes may lead to the creation of new and improved alternatives to both plastic and paper straws, which could further shape the future of the industry.
Build Trust with Customer Feedback
“We’ve been using YINGKE’s Paper Straw Making Machine for over a year now, and the results have been outstanding. The machine is incredibly fast, producing high-quality paper straws that are durable and meet our customers’ eco-friendly expectations. It has helped us scale up our production while maintaining a competitive edge in the market.”
— Mark Thompson, CEO,
“The customization options on YINGKE’s Paper Straw Machine have been a game-changer for our business. We can now offer various sizes and designs of paper straws, including custom-printed options, which have really boosted our sales. The machine is easy to operate, and the after-sales support has been fantastic.”
— Sophia Liu, General Manager
“As sustainability becomes more important to our customers, YINGKE’s Paper Straw Machine has allowed us to meet their needs with an eco-friendly alternative. The machine is efficient and energy-saving, and the paper straws we produce are of excellent quality, completely biodegradable, and sturdy enough for long-term use.”
— John Martinez, Operations Manager
“The reliability and speed of YINGKE’s Paper Straw Making Machine have exceeded our expectations. We’ve experienced minimal downtime, and the machine produces consistent, high-quality paper straws that meet all regulatory requirements. The transition to paper straws has been seamless, thanks to YINGKE’s support and superior machinery.”
— Emma Green, Production Head
Explore More Solutions
Looking for additional straw production solutions? Check out our range of machines designed to meet all your production needs.
Frequently Asked Questions
1. What materials does the Paper Straw Making Machine use?
The machine uses food-grade, eco-friendly paper that is biodegradable and compostable, ensuring compliance with environmental standards.
2. What is the production capacity of the machine?
The machine can produce up to 700 paper straws per minute, depending on the size and configuration of the straws.
3. Can I produce different sizes and designs of paper straws?
Yes, the machine is designed to create paper straws in various diameters, lengths by changing parts.
4. How energy-efficient is the machine?
The machine is equipped with energy-saving components and consumes 4.5KW-6.5 kW, making it both eco-friendly and cost-effective to operate.
5. What kind of after-sales support do you offer?
We provide comprehensive after-sales support, including remote troubleshooting, spare parts supply, and on-site training for your team.
6. What's the lead time of your machine?
We normally deliver the machine in 35 days after down payment is received.
7. Do you provide any spare parts with the machine?
Yes, we will give some parts for free with the machine.
