Ճկուն ծղոտի պատրաստման մեքենա
Efficient, Cost-Effective, and Customizable. Empower your business with our advanced flexible straw production technology.
About the straw bending machine
Revolutionize your straw production with this 021 flexible straw making machine - the ultimate forming machine designed to effortlessly bend straight drinking straws into flexible ones. With complete automation from start to finish, all you need to do is add the straight straws to the hopper and let the machine do the rest. The straws are fed one by one into the main drum, clamped by two mechanical hands, and rotated through two rotary dies to achieve a perfect, die-pressed effect. Then, with two mechanical hands, they are compressed to form high-quality, flexible straws that are outputted automatically. With a main drum that continuously operates with 12 straws, this machine boasts a higher production capacity for optimal efficiency.
Why Choose Our Flexible Straw Making Machine?
Reliable stable working performance
Production counting
quantity pre-set, alarming when the pre-set value reached
Automatic stop when at fault
200-300pcs/min
Compatible with PP/PLA straw
Branded components, Delta inverter, Wannan Motor,Schneider/CHNT Electrical Components
Watch the Flexible Straw Making Machine in Action
Specification table
Below is the basic information of the machine
| Մոդել | 021 Series Flexible straw making machine(Flexible straw bending machine) | |||
| Էլեկտրամատակարարում | 1.5KW(VFD) 380V 50HZ 3P | |||
| Տարողություն | 200-300pcs/min | |||
| Ծղոտի ճշգրտում | Ներքին տրամագիծը (Ստանդարտ) | Φ3.8mm | Φ4.8mm | Φ5.8mm |
| Ուղիղ ծղոտի երկարությունը | 165~245mm | 200~260mm | 200~260mm | |
| Thickness of straw | 0.18±0.03mm | 0.15±0.03mm | 0.15±0.03mm | |
| Length of finished straw | 150~230mm | 185~245mm | 185~245mm | |
| Front section length of finished straw | 30~50mm | |||
| Մեքենայի չափը | 1.5m*1.5m*1.7m | |||
| Քաշը | 1000 կգ | |||
Please feel free to contact us if you have any special requirements
Information needed
Top Section(A) Length ----
Number of Teeth(B) -----
Straw inner diameter -----
Straw thickness -----
Straw material -----
Related Machines
Find more of our machines for your needs
Frequently Asked Questions
1. What shall we provide if want to buy this machine
---the straw inner diameter, straw length, and straw material. also voltage, better to give us your target production capacity
2. Can we make different diameters of straw in one machine?
--- Nope, one diameter one machine
3. What's the production capacity of this machine?
---this flexible straw making machine with a range of 200-300pcs/min,average around 250pcs/min
4. What's the lead time of this machine ?
--- Normally we can start production after the deposit is received,and can make delivery within 35 days
5. Do you provide any warranty for the machine?
---Yes, we give one year warranty to our customers, Customers can get online support all the time, we don't do one time business.
6. What about the spare parts supply?
--- For all the machines we sold, we can provide spare parts as requested.so it won’t affect your normal production.
